Microscope Type

Trinocular Microscopes

Separate Eyepiece

10x/20 (20mm Field of View) 30mm mounting diameter Available fixed or focusing Available with or without pointer Focusing eyepieces with reticle holder for 21mm reticle Foldable eyeguards High eyepoint

EZTube

10x/18 (18mm Field of View) 45 degree viewing angle Attaches to stand with set screw Available with pointer and without pointer Captive thumbscrew availablity for safe rotation Eyepieces are integrated into tube Interpupillary Distance Range 52mm – 75mm Preset Diopters for corrected vision

Other Viewing Tubes for Separate Eyepieces

45 degree, 30 degree, Trinocular Eyepiece locking screw Interpupillary Distance Range 52mm – 75mm Leica Tube dovetail standard Maximum Field of view 20mm Rotatable dovetail

Stand

4 position nosepiece only Drop in holder for 32 mm mounted or not mounted filters External fuses Knurled nosepiece Stand construction – die cast aluminium Stand shape protects controls

EZStore

Cord wrap Undercut in front of stand Vertical cord attachment to stand Vertical handle

Objectives

100x dry objective with N.A. 0.8 (no correction collar) HI Plan for FOV 20 Infinity Platform M25 nosepiece thread Objective labeling laser engraved (HI Plans) Plan optics for FOV 18

EZGuide

26mm x 76mm stage travel One handed slide loading

SafeTStage

Non extending rack Rounded stage edges Stage surface 185mm (150mm front) wide X 140mm deep Verniers for X/Y coordinates

Condenser

Prefocused and Precentered Condenser Slot in condenser for contrast sliders (Phase, Darkfield, Compensator) Magnification labels on condenser

Focusing

Low position focus controls Self adjusting focus mechanism 300 microns per fine focus rotation Calibrated in 3 micron increments

EZLite

Continuous intensity adjustment Illumination enough for viewing at lowest intensity LED illumination - 6000 K temp, 25,000 h life at full intensity Preset Field aperture only Simple Polarizing Kit available

Imaging

Trinocular tubes available (50%/50% light split) C mount adapters with standard Leica mount ICC50 Intermediate Camera Module (50%/50% light split) Stand Alone kit for ICC50 Camera Module (Power supply, Analog Video Cable)

Intermediate Modules

15mm Flat top module 35mm Intermediate Ergo module available Analyzer Module with pin for Viewing Tube alignment Module for LSF Reflected Light Illuminator

AgTreat

Anti Microbial Treatment

Certifications

CE cULus RoHS
